環境參數

Standard versions: IEC 60529 IP44. PI and FG versions: IEC 60529 IP55

輸入連接

Phoenix/Euroblock style screw terminals; PI and FG versions include dual-gland-nut input-panel cover

額定阻抗

Passive: N/A, Bi-amp: 4 Ω Biamp

頻率響應(-3分貝)

40 - 2600Hz

頻率響應(-10分貝)

30 - 3200Hz

建議高通頻率

35Hz

靈敏度(1瓦/1米)

101dB

最大. 聲壓級/1米 (計算)

137dB

覆蓋(-6dB標準)水平

Omnidirectional dddd°

覆蓋(-6dB標準)垂直

Omnidirectional dddd°

系統功率處理(連續/音樂//峰值)

1000/2000/4000 Watts

低頻換能器

Two DVX3159A 15-inch (381 mm) drivers

最小負荷阻抗

Passive: N/A, Bi-amp: 2.7 Ω Biamp

箱體材料

13-ply weather-resistant birch with EVCoat

柵格

Standard versions: 16-ga Galvanneal, Powdercoat, with screen behind. PI and FG versions: 18-ga Stainless, Powdercoat, with hydrophobic cloth behind

吊掛

(28) M10 Threaded Points (one EBK-M10-EVI kit of four forged eyebolts included)

高度

768.6mm (30.26")

寬度

675.6mm (26.6")

深度

726.4mm (28.6")

凈重

53.1kg (117.07lbs)
