環(huán)境參數

Standard versions: IEC 60529 IP44 PI and FG versions: IEC 60529 IP55

輸入連接

Phoenix/Euroblock style screw terminals; PI and FG versions include dual-gland-nut input-panel cover

內置無源分頻點

1450Hz

頻率響應(-3分貝)

58 - 16000Hz

頻率響應(-10分貝)

49 - 19000Hz

建議高通頻率

65Hz

靈敏度(1瓦/1米)

98dB

最大. 聲壓級/1米 (計算)

131dB

系統(tǒng)功率處理(連續(xù)/音樂//峰值)

500, 1000, 2000 Watts

低頻換能器

SMX2121 12-inch (305 mm) driver

高頻換能器

ND2B 2-inch (51 mm) diaphragm compression driver

額定阻抗

8 Ω

最小負荷阻抗

6 Ω

箱體材料

13-ply weather-resistant birch

柵格

Standard versions: 16-ga Galvanneal, Powdercoat, with screen behind PI and FG versions: 18-ga Stainless, Powdercoat, with hydrophobic cloth behind

吊掛

(22) M10 Threaded Points (one EBK-M10-EVI kit of four forged eyebolts included)

高度

768.6mm (30.26")

寬度

406.3mm (16")

深度

413.3mm (16.27")

凈重

28.6kg (63.05lbs)
